Sanwa Indonesia - Sanwa Analog Multitesters

Sanwa EM7000, CX506a, SH-88TR, YX-361TR, SP-18D, SP20, SP21, YX360TRF, TA55, AP33, CP-7D, VS-100

Analog Multitesters／FET Tester

Basic Features

■High input impedance (DCV2.5〜12MΩ/V), and 0.12μA range (DCA)
■Bandwidth 40Hz〜1MHz AC sign wave
■Rectangular pulse P-P (Peak to Peak) measurement (duty cycle 20% and above)
■Wide ohm range 0.2Ω〜200MΩ
Bandwidth : 40Hz〜1Mhz (12V range and below)

Analog Multitesters／Multifunction

Basic Features

■26ch switch, wide range measurement
■Capacitance measurement 50pF〜2000μF
■High input impedance 50kΩ / V (DC3〜300Vrange)
■Switchable DC polarity
Bandwidth : 40Hz〜30kHz (3V and 12V),　40Hz〜10kHz (30V range)

Analog Multitesters／Multifunction

Basic Features

■Total 35 wide ranges (22ch sw + additional functions)
■Capacitance measurement 1μF〜1F
■LED for continuity check

Analog Multitesters／Multifunction

Basic Features

■Total 35 wide ranges (24ch sw + additional functions)
■±DCV zero center meter
■LED for continuity check
■OUTPUT terminal (series capacitor terminal)
■Battery check

Analog Multitesters／Drop shock proof meter

Basic Features

■Low power ohm (3V) measurement up to 200MΩ
■Capacitance measurement 0.01μF〜1000μF
■LED check by 3V terminal voltage at resistance range
■Battery check
■Protective body cover
Bandwidth : 30〜80kHz (AC12V), 30〜20kHz (AC30V)

Analog Multitesters／Drop shock proof meter

Basic Features

■20ch measurement ranges
■Capacitance measurement 500μF
■Tilt stand
■DC high voltage and temperature measurement (with optional accessories)
Bandwidth : 40〜100kHz (AC10V)

Analog Multitesters／Drop shock proof meter

Basic Features

■Drop shock proof taut-band meter
■±DCV zero center meter
■Fuse and diode protection
■Battery check
■Tilt stand
Bandwidth : 40〜100kHz (AC12V)

Analog Multitesters／Drop shock proof meter

Basic Features

■Drop shock proof meter
■ Null (zero center) meter ±5 / ±25 in DCV
■ High resistance up to 200MΩ with low voltage
■ Protective body cover
■ Capacitance, dB, Li measurement
Bandwidth : 30〜100kHz (AC10V)

Analog Multitesters／Automotive

Basic Features

■High level panel visibility
■Continuity check buzzer
■Tilt-stand
■Measureable up to DC30A / DC300A with optional clamp probe
■Automotive battery check (12V)

Analog Multitesters／Slim & compact

Basic Features

■Elastomer material absorbs shock from fall
■High-durability nylon-woven copper lead
■Using elastomer material improves flexibility and reduces the stress on the lead wire and the probe when bent.

Analog Multitesters／Slim & compact

Basic Features

■Wide scale panel with mirror
■Affixed test leads providing better safety
■High-precision, non-flammable, smokeless metal-oxide film resistor
■Battery check
■Fuse and diode circuit protection

Analog Multitesters／Priority to safety

Basic Features

■For lower voltage circuit (500V and below) with large capacitance
■Current-limiting fuse that can interrupt 100kA, is installed.
■All ranges are protected from input voltage up to 500V
■Carrying case
Bandwidth : 40〜10kHz (50V and below)
